Internal Structure of Diffuse Silicon Pressure sensor

From: Issued date 2023.02.13 Back

Diffuse silicon pressure sensor is the core component for manufacturing pressure sensors and transmitters. Taking Nanjing Wotian diffusion silicon pressure core as an example, I will talk about the internal structure of the diffuse silicon pressure sensor.

Tip: Internal Structure of Diffuse Silicon Pressure sensor

Diffuse silicon pressure sensor is composed of compensation plate, steel ball, base, O-ring, chip, ceramic pad, diaphragm, pressure ring, silicon oil, etc.

In the structure in figure, each part has a corresponding role and characteristics



Compensation board: signal amplification



Steel ball: sealing oil



Base: the carrier of the pressure sensor



O-ring: sealed



Chip: Feeling Stress



Ceramic Mat: Filled



Diaphragm: contact liquid or gas for measurement



Pressure ring: welding the diaphragm to the base



Silicon oil: conductive pressure



The above is about the structure and function of Nanjing Wotian pressure sensor. If you have some words, welcome to talk with the editor.
